■ Hauv daim ntawv thov ntawm PON (Passive Optical Network: Passive Optical Network) thev naus laus zis, OLT cov cuab yeej yog cov cuab yeej tseem ceeb hauv chaw ua haujlwm.
■ Txuas nrog rau pem hauv ntej-kawg (txheej txheej) hloov nrog lub network cable, hloov nws mus rau hauv lub teeb liab kho qhov muag, thiab sib cuam tshuam nrog lub optical splitter ntawm tus neeg siv kawg nrog ib qho fiber ntau optical.
■Realize functions xws li kev tswj, kev tswj, thiab ntsuas qhov deb ntawm ONU ntawm tus neeg siv kawg.
■OLT cov cuab yeej, zoo li ONU cov cuab yeej, kuj yog cov khoom siv optoelectronic integrated.
|
Qauv |
HEP5800-04P |
|
Khoom configuration |
4 * GEPON SFP, 4 * 10GE / GE SFP, 4 * 10/100/100 BaseT, AC / DC dual fais fab mov yeem |
|
Lub cev interface |
1RU19 nti Cassette; |
|
1 ntxiv rau 1 Lub zog rov ua dua; |
|
|
EPON Chaw nres nkoj: 4 EPON chaw nres nkoj, hom GEPON SFP; |
|
|
Upstream Hluav Taws Xob Chaw nres nkoj: 4 gigabit hluav taws xob chaw nres nkoj, gigabit hluav taws xob chaw nres nkoj tuaj yeem hloov mus rau 10/100/1000M, hom RJ45; |
|
|
Uplink Optical Ports: 4 10Gigabit optical ports, 10 Gigabit optical ports txhawb Gigabit optical, hom SFP / SFP ntxiv / LC; |
|
|
Console Chaw nres nkoj: kev tswj qhov chaw nres nkoj, siv rau kev tswj hwm kab lus, hom RS232; |
|
|
Hom C Interface: Hom-C tswj interface, siv rau cov cuab yeej hais kom ua kab teeb tsa tswj, hom C; |
|
|
RST Chaw nres nkoj: pib dua qhov chaw nres nkoj, siv rau kev pib pib dua thiab pib dua ntawm lub cuab yeej |
|
|
Mechanical qauv |
Chassis plhaub: hlau plhaub, cua txias; |
|
Fais fab kiv cua: Modular tsim ntawm lub hwj chim mov, txhawb kev sib pauv kub. ob lub kiv cua ruaj khov; |
|
|
Chassis loj: Dimensions (ntev * dav * qhov siab) (mm) 440 * 260 * 44; |
|
|
Txoj kev txhim kho: txheem 19-inch 1U khib-mounted installation; |
|
|
Nta |
Kev them nyiaj yug 1: 64 cais piv, tag nrho lub tshuab txhawb 256 ONU nkag; |
|
Txhawb SP / WRR / SP ntxiv rau WRR qhov tseem ceeb algorithm kom ntseeg tau tias kev sib kis ntawm ntau yam kev pabcuam tseem ceeb ntws los ntawm kev thov; |
|
|
Txhawb ntau qhov chaw nres nkoj mirroring tsom xam muaj nuj nqi, txhawb mirroring tsom xam raws li kev lag luam khiav; |
|
|
Txhawb kev ua haujlwm zoo li qub thiab hloov pauv QinQ; |
|
|
Txhawb IPv4 / IPv6 dual raws tu qauv pawg platform, txhawb IPv4 / IPv6 static routing; |
|
|
Kev them nyiaj yug IPv4 / IPv6 dual raws tu qauv pawg platform, txhawb RIP / OSPF thiab lwm yam kev coj ua; |
|
|
Txhawb kev tswj hwm kev teeb tsa raws li WEB nplooj ntawv; |
|
|
Txhawb Hom-C interface tswj; |
|
|
Txhawb lub zog tsis ua hauj lwm tswb ntawm tag nrho lub tshuab; |
|
|
ib puag ncig ua haujlwm |
Ua haujlwm kub: -15 degree -55 degree ; |
|
Cia kub: -40 degree -70 degree ; |
|
|
txheeb ze humidity: 10 feem pua -90 feem pua, tsis muaj condensation; |
|
|
Kev siv fais fab |
Fais fab mov specifications: 1 ntxiv rau 1 redundant fais fab mov, AC / DC yeem; |
|
input zog: AC: input 100-240V, 47-63Hz; DC: 36V -75V; |
|
|
Kev siv hluav taws xob tag nrho ntawm lub tshuab: tag nrho cov khoom siv hluav taws xob tsawg dua lossis sib npaug ntawm 49W, tsis siv zog siv tsawg dua lossis sib npaug li 25W; |
