10Gbps 1310nm 20km LC SFP ntxiv
SFP ntxiv rau transceivers yog kev ua haujlwm siab, cov nqi siv tau zoo txhawb cov ntaub ntawv tus nqi ntawm 10Gbps thiab 20km kis nrug deb nrog SMF. Lub transceiver muaj peb ntu: DFB laser transmitter, PIN photodiode integrated nrog trans-impedance preamplifier (TIA) thiab MCU tswj chav tsev. Tag nrho cov modules txaus siab rau chav kawm I laser kev nyab xeeb. Cov transceivers tau tshaj SFP Multi-Source Agreement thiab SFF-8472 digital diagnostics functions.
Optical yam ntxwv
|
|
Chav tsev |
Tus nqi |
|
Kev khiav hauj lwm ncav |
m |
10K |
|
Kev xa tawm |
||
|
Nruab nrab wavelength (ntau) |
nm |
1260 -1355 |
|
Sab Hom Kev Tiv Thaiv Tus Nqi (min) |
dB |
30 |
|
Launched zog |
||
|
- qhov siab tshaj plaws |
dBm ib |
ntxiv rau 0.5 |
|
- yam tsawg kawg nkaus |
dBm ib |
-8.2 Notes1 |
|
OMA |
dBm ib |
-5.2 |
|
OMA-TDP (min) |
dBm ib |
-6.2 |
|
Transmitter thiab dispersion txim |
dB |
0 Notes4 |
|
Nruab nrab tso tawm fais fab ntawm OFF transmitter (max) |
dBm ib |
-30 |
|
Extinction ratio (min) |
dB |
3.5 Lus Cim 2 |
|
RIN12 OMA (max) |
dB/Hz |
-128 |
|
Optical Return Poob Tolerance (min) |
dB |
12 |
|
Tus txais |
||
|
Nruab nrab wavelength (ntau) |
nm |
1260-1355 |
|
Tau txais overload (max) hauv nruab nrab lub zog 1 |
dBm ib |
0.5 |
|
Tau txais rhiab heev (min) hauv nruab nrab lub zog1 |
dBm ib |
-14.4 Notes3 (10km) |
|
dBm ib |
-13.4 Notes3 (20km) |
|
|
Txais rhiab heev (max) hauv OMA (cov lus hauv qab 2) |
dBm ib |
-12.6 Notes3 (10km) |
|
dBm ib |
-11.6 Notes3 (20km) |
|
|
Reflectance (max) |
dB |
-12 |
|
Stressed receiver rhiab heev (max) hauv OMA2 |
dBm ib |
-10.3 |
|
Vertical qhov muag kaw nplua (min)3 |
dB |
2.2 |
|
Stressed qhov muag jitter (min) 2 |
UA-p |
0.7 |
|
Txais hluav taws xob 3dB sab sauv txiav tawm zaus (max) |
GHz |
12.3 |
|
Lub hwj chim txais (kev puas tsuaj, Max) |
dBm ib |
1.5 |
Cov yam ntxwv hluav taws xob
|
Parameter |
Cim |
Min. |
Hom |
Max |
Chav tsev |
Sau ntawv |
|
Cov ntaub ntawv tus nqi |
|
- |
10.3125 |
- |
Gbps |
|
|
Kev siv fais fab |
|
- |
1200 |
1500 |
mW |
|
|
Transmitter |
||||||
|
Single Ended Output Voltage kam rau ua |
|
-0.3 |
- |
4.0 |
V |
|
|
C hom voltage kam rau ua |
|
15 |
- |
- |
mV |
|
|
Tx Input Dif Voltage |
VI |
400 |
|
1600 |
mV |
|
|
Tx Fault |
VoL |
-0.3 |
|
0.4 |
V |
Ntawm 0.7mA |
|
Data Dependent Input Jitter |
DDJ |
|
|
0.10 |
UI |
|
|
Cov ntaub ntawv nkag tag nrho Jitter |
TJ |
|
|
0.28 |
UI |
|
|
Tus txais |
||||||
|
Single Ended Output Voltage kam rau ua |
|
-0.3 |
- |
4.0 |
V |
|
|
Rx tso zis qhov sib txawv Voltage |
Vo |
300 |
|
850 |
mV |
|
|
Rx tso zis nce thiab caij nplooj zeeg |
Tr/Tf |
30 |
|
|
ps |
20 mus rau 80 feem pua |
|
Tag nrho Jitter |
TJ |
|
|
0.70 |
UI |
|
|
Deterministic Jitter |
DJ |
|
|
0.42 |
UI |
|
