1GE ONU muaj ib qho 10/100/1000M RJ45 chaw nres nkoj, xim dawb, AC 110V ~ 220V fais fab adapter. Nws yog GPON-based ntaus ntawv, tsom rau hauv tsev thiab SOHO (cov chaw ua haujlwm me thiab chaw ua haujlwm hauv tsev) cov neeg siv khoom. FTTH GPON ONU yog ib qho ntawm GPON optical network chav tsim tsim uas ua raws li cov kev xav tau ntawm kev siv broadband. GPON network yog siv hauv FTTH / FTTO los muab cov ntaub ntawv thiab cov kev pabcuam video.
1GE ONU muaj ntau yam kev pabcuam rau cov neeg siv khoom, suav nrog kev siv Internet ceev, kev xav tau video, kev sib tham video, thiab xa cov ntaub ntawv loj. Nws tuaj yeem muab cov neeg siv khoom nrog ntau cov kev pabcuam thiab ua tau raws li cov kev xav tau ntawm cov neeg nqa khoom-chav FTTH optical network davhlau ya nyob twg nrog kev txhawb nqa ntawm NGBN Saib NMS.
|
Qauv |
H307 |
|
Qhov Loj (L * W * H) |
90mm (L) × 90mm (W) × 24 hli (H) |
|
Optical teeb liab nkag |
GPON |
|
Tus neeg siv interface |
1 GE |
|
Qhov taw qhia lub teeb |
POWER/PON/LOS/LAN |
|
Khawm |
Fais fab hloov khawm, Pib dua khawm |
|
Qhov hnyav |
95g |
|
Fais fab adapter input |
100V-240V AC,50Hz-60Hz |
|
PowerSupply xav tau |
12V DC, 0.5A |
|
Kev siv fais fab |
<6w |
|
Ua haujlwm kub |
-10 degree ~ ntxiv rau 45 degree |
|
Ib puag ncig humidity |
5% ~ 95% (tsis-condensing) |
|
PON interface |
|
|
Module hom |
PX20 ntxiv / Chav B ntxiv rau SC / UPC lossis SC / APC |
|
Ua haujlwm wavelength |
nce 1310nm, nqis 1490nm |
|
TX Optical power value |
0 5-4dbm |
|
RX Optical zog rhiab heev |
-28dBm |
|
Kev sib kis nrug |
0-20km |
|
Tus nqi kis tau tus mob |
GPON: Uplink 1.244Gbps; downlink 2.488Gbps |
|
Ethernet interface |
|
|
Hom interface |
RJ 45 |
|
Interface parameters |
1 x 10/100/1000Mbps auto adaptive Ethernet interfaces |
