1.25g 1310nm 40km Lc SFP
2

1.25g 1310nm 40km Lc SFP

Xa kev nug

Khoom Taw qhia

SFP yog ib qho khoom siv sib txuas uas hloov cov teeb liab gigabit hluav taws xob rau hauv cov teeb liab kho qhov muag. Nws yog kev lag luam-tus qauv me me thiab pluggable gigabit optical transceiver module. Nws tuaj yeem siv rau ntawm SFP cov chaw nres nkoj ntawm cov khoom siv hauv network xws li keyboards, routers, thiab media converters. Siv los txuas kho qhov muag lossis tooj liab network cables rau kev xa cov ntaub ntawv, feem ntau pom muaj nyob rau hauv Ethernet keyboards, routers, firewalls thiab network interface cards Optical thiab hluav taws xob yam ntxwv

Parameter		Cim		Min	Hom	Max	Chav tsev	Sau ntawv
Transmitter
Center Wavelength			λc	1260	1310	1360	nm
Spectral Dav (RMS)			∆λ			4	nm
Nruab Nrab Output Fais Fab			Pout	-9		-3	dBm ib	1
Extinction Ratio			ER	9			dB
Optical Rise / Poob Lub Sijhawm (20 feem pua ~ 80 feem pua)			tr/tf			0.26	ns
Data Input Swing Differential			V_IN	400		1800	mV	2
Input Differential Impedance			Z_IN	90	100	110	Ω
TX Disable	Disable			2		Vcc	V
TX Disable	Pab			0		0.8	V
TX Fault	txhaum			2		Vcc	V
TX Fault	Ib txwm			0		0.8	V
Tus txais
Center Wavelength			λc	1260		1580	nm
Tus txais rhiab heev						-23	dBm ib	3
Txais Kev Tshaj Tawm				-3			dBm ib	3
LOS De-Assert			LOS_D			-24	dBm ib
LOS Assert			LOS_A	-30			dBm ib
LOS Hysteresis				1		4	dB
Data Output Swing Differential			Vout	400		1800	mV	4
LOS			Siab	2		Vcc	V
LOS			Tsawg			0.8	V

Bsolute Maximum Ratings
Parameter	Cim	Min	Max	Chav tsev
Cia kub	TS	-40	85	degree
Fais fab mov Voltage	Vcc	-0.5	4	V
txheeb ze humidity	RH	5	95	feem pua
Teeb liab input voltage		-0.3	Vcc plus 0.3	V
Tus txais kev puas tsuaj pib		5		dBm ib
